40ft High Cube Refrigerated Container Specifications
| Exterior | Interior | Door Openings | Trip Weight | Fork Pockets |
Length: 40' Width: 8' Height: 9' 6" | Length: 37' 11" Width: 7' 6" Height: 8' 4" | Width: 7' 6" Height: 8' 4" | Tare: 9,590 lbs Max Gross: 70,550 lbs Cubic Cap: 2,380 cu. ft | Height: 0' 4 1/2" Width: 1' 2 3 /16" Center: 6' 9 7/8" |
The 40-foot High Cube Refrigerated Container is engineered to maintain an impressive temperature range from 75 to -20 degrees Fahrenheit. This capability is essential for various applications, particularly for businesses requiring stable, cold environments for food storage, pharmaceuticals, or chemical supplies. The versatility of this container makes it an optimal choice for transporting temperature-sensitive goods across long distances while ensuring the highest quality upon arrival.
Designed to operate on both 50 and 60 Hz power supplies, our refrigerated containers require a grounded electrical system with circuit breakers rated at a minimum of 30 amps. For power supplies utilizing 208/230 volts, circuit breakers must be rated at least 50 amps. The robust electrical system supports a voltage variance of (+) or (-) 15%, ensuring reliable performance. Additionally, the internal circuit breakers protect both the fan motors and control circuits, safeguarding your investments.
The 40ft High Cube Refrigerated Container boasts the following specifications:
Exterior Dimensions: Length: 40', Width: 8', Height: 9' 6"
Interior Dimensions: Length: 37' 11", Width: 7' 6", Height: 8' 4"
Tare Weight: 9,590 lbs
Maximum Gross Weight: 70,550 lbs
Cubic Capacity: 2,380 cu. ft
The container also features convenient fork pockets for easy maneuverability, making it suitable for various applications, from warehouse storage to shipping logistics.
Upon delivery, each refrigerated unit is equipped with a 460-volt cable featuring a standard ISO CEE 59-foot power plug, although the 230-volt cables do not include power plugs. We recommend discussing the specific electrical needs with our team to ensure optimal setup for your operation.
High Cube Refrigerated Containers provide an ideal solution for businesses that prioritize both quality and space. With their additional height compared to standard containers, they allow for greater storage flexibility. This makes them especially suitable for perishable goods, ensuring that everything from fresh produce to delicate pharmaceuticals can be transported safely and efficiently.
As the demand for reliable cold storage solutions continues to rise, investing in a 40ft High Cube Refrigerated Container ensures you are well-equipped to meet the needs of your customers while adhering to industry standards.
At Agile Star, we offer a range of refrigerated containers, from new to used, tailored to suit your specific cold storage requirements. Our team is dedicated to helping you find the best solution for your needs.
For more information about our products, please visit our refrigerated container products page or contact us today. Let us help you enhance your storage capabilities with our state-of-the-art containers!
